Understanding a large variety of confusing specifications is one of the most challenging aspects of selecting a new vacuum cleaner. First and foremost, consumers want vacuum cleaners that offer the best cleaning ability. And most consumers typically equate cleaning ability with "power" or "suction".
Cleaning ability is not just about power and suction, even though these attributes are important elements of vacuum cleaner performance. With a little information and education, you will be able to sift through the numbers and better understand what the specifications mean and which ones are important to you.
Unfortunately, there is no single rating that indicates cleaning ability. However, there are a number of primary specifications, that when clearly understood, allow consumers to make educated decisions concerning which vacuum cleaner will have the best cleaning ability.
These primary specifications include watts, amps, volts, water lift (or sealed suction), horsepower, air watts, and airflow.
There are also a number of other, secondary specifications that influence cleaning ability that we'll also examine. These include filtration, cleaning tools (agitation), capacity, quality, noise, features and cost.
In order to make sense of all this we first need to understand the basics of how a vacuum cleaner works.
All vacuum cleaners operate based on air flowing from the opening at the cleaning head or tool, through the vacuum cleaner and the bag and/or filter system and then out the exhaust port. This airflow is created by the vacuum motor, which also may be referred to as the suction motor.
The vacuum motor consists of electrical components attached to a fan or multiple fans. When the fans spin, a partial vacuum is created and the pressure inside the vacuum cleaner drops below the ambient (or existing) air pressure in the room. Because air pressure is higher outside the vacuum cleaner than inside, air rushes through the vacuum cleaner.
So, it is easy to see that the vacuum motor is the heart of a vacuum cleaner. After all, the more powerful the motor, the greater the pressure differential and therefore the more suction and airflow, right? And it is for this reason that most of the specifications you see concerning cleaning ability relate either directly or indirectly to the motor.
But here's where it gets tricky. Specifications for components such as the motor do not necessarily relate to the performance of the entire vacuum cleaner, and therefore are only a part of the story.Read more about it at http://www.themaidsma.com
Let's take a look at the primary specifications one by one:
The input power of the vacuum motor is measured in watts. Although this specification doesn't take into account the efficiency of the motor, the number of fans or the overall vacuum cleaner design, motor wattage is a valid way to evaluate and compare the power of the motor.
While the ideal comparison is motor input power in watts of Product A compared to motor input power in watts of Product B, some manufacturers do not provide motor input power specifications in the form of watts but instead rate the entire vacuum cleaner in amps. This can make it hard to compare across brands.
However, you can convert amps to watts by the formula, amps x 120 (volts) = watts. Or conversely, you can convert watts to amps by the formula, watts/volts (always 120) = amps. For example, a 1400-watt motor converts to 11.67 amps (1400/120=11.67).
Comparing machines rated in amps with those rated in watts is not an exact comparison because manufacturers that are using watt ratings typically rate the motor only while amperage ratings use the total electrical consumption of the vacuum cleaner including the motor in the power nozzle (the motorized revolving brush cleaning head), light bulb, etc.
This means that a Power Team (a canister vacuum cleaner with a power nozzle) with a specification of 12 amps might be quite comparable to another Power Team with a 1200-watt motor that converts to only 10 amps.
This is because the power nozzle motor consumes 1.5 amps, the bulb uses additional amperage and so on. So, if we subtract the amperage used by the power nozzle motor from our 12 amp machine, we come up with 10.5 amps for the motor and light bulb. In this example, the two motors both have ratings of very close to 10 amps, and therefore, equivalent motor input power.
Therefore, it is best to either compare motor input power in watts of both machines or if you have to compare a machine rated in watts with one rated in amps, try to get the amperage rating of the motor only instead of the entire vacuum cleaner. You can then convert this to watts and have a meaningful comparison.
A very common vacuum cleaner specification is amps. The amperage rating designates the maximum amount of electrical current used by all of the vacuum cleaner's electrical components when operating. The biggest consumer of electrical current will be the vacuum motor, but the amperage rating includes all of the electrical components, including the vacuum motor, the power nozzle motor, the light bulb, etc.
The maximum amp "draw," (the number of amps the vacuum cleaner uses when running) allowed for any appliance that plugs into a standard household outlet is 12. Therefore, if you see amperage ratings above 12, read the fine print, as they are not true amperage specifications but some other manufacturer developed "performance rating" designed to create the impression of a more powerful vacuum cleaner.
Although amperage refers to electricity consumption and not power or cleaning ability per se, it can be used to compare the input power of one vacuum cleaner to another. This is because while input power is measured in watts, amps are converted into watts by multiplying by volts. Since volts are constant at 120, amps represent a valid comparison of motor input power.
Again, as mentioned above, when making this comparison, try to get the amp rating of the motor only instead of the entire machine.
Therefore, amp ratings give us a means of comparing the input power of a vacuum motor and the vacuum cleaner as a whole and are a meaningful specification for comparison purposes. But again, they are only part of the story. After all, just because a motor or vacuum cleaner consumes more electricity, this does not make it a better cleaner.
The amps specification also does not take into account how efficient the motor is, as well as other design factors, such as whether the motor has one or two fans (two is not necessarily better than one) and the overall efficiency of the vacuum cleaner design.
In the United States, standard household current operates at 120 volts at the meter. Voltage within a home is sometimes referred to as "110" and this is because there may be voltage drops through the house wiring. But not to worry, appliances are designed to operate within a range of voltages from 110 to 120.
For the purposes of understanding vacuum cleaner specifications the only thing about voltage we really need to know is the formula, amps x volts = watts and conversely, watts/volts = amps. When doing these calculations use 120 volts for U.S. appliances.
Water Lift (Sealed Suction)
The sealed suction of a vacuum cleaner is measured in inches of water lift. This rating is taken when the motor is totally sealed, and the term refers to how many inches the motor will vertically lift a 1" column of water.
Water lift is what gives a vacuum cleaner the power to pick up or "lift" debris from the floor surface, while airflow then removes it to the dust bag. Vacuum cleaners with more inches of water lift will have an easier time picking up sand and other heavier soils from carpet and flooring.
Water lift is also a measure of a vacuum cleaner's ability to deal with resistance within the vacuum cleaner. This is especially important in HEPA or high filtration vacuum cleaners that have more resistance due to the additional filters that the air has to pass through.
A good water lift rating also indicates that a vacuum cleaner will keep performing at high levels as the dust bag or container fills and the filters "load" or gradually fill with fine particulate and become more and more resistant to air passing through.
The water lift of a vacuum cleaner is another useful indicator of performance in that it is a means of comparing the suction of one motor to another and, generally speaking, the more water lift the better.
This is a rating that was used primarily for marketing purposes and had little or no relation to vacuum cleaner performance in the real world. Thankfully, it has been largely done away with as a vacuum cleaner specification.
